Key Benefits
High-Efficiency Production
A maximum spindle speed of 4200 rpm combined with rapid traverse rates of 24 m/min allows faster cycle times and improved production throughput.
Stable Accuracy for Precision Components
The machine achieves positioning accuracy of 0.005 mm and repeatability of 0.005 mm, ensuring reliable dimensional consistency during batch production.
Fast Tool Change Performance
The 12-station servo turret completes tool changes in only 0.23 seconds, reducing idle time and supporting complex multi-process machining.
Heavy-Duty Cutting Capability
Powered by a 15/18.5 kW spindle motor delivering up to 95.5 Nm torque, the DC600 can handle both precision finishing and demanding roughing operations.
Flexible Configuration Options
Customized spindle configurations, tooling arrangements, control systems, and automation solutions are available to meet specific production requirements.
Technical Specifications
|
Item |
DC600 |
|
Maximum Swing Diameter |
Φ500 mm |
|
Maximum Machining Length |
500 mm |
|
Maximum Machining Diameter |
Φ350 mm |
|
Spindle Through Hole Diameter |
Φ65 mm |
|
Maximum Bar Capacity |
Φ52 mm |
|
Maximum Spindle Speed |
4200 rpm |
|
Spindle Nose |
A2-6 |
|
Chuck Size |
8" |
|
X-Axis Travel |
210 mm |
|
Z-Axis Travel |
535 mm |
|
X/Z Rapid Traverse |
24 / 24 m/min |
|
Number of Tools |
12 |
|
Tool Change Time |
0.23 s |
|
OD Tool Holder Size |
25 × 25 mm |
|
Maximum ID Tool Diameter |
Φ40 mm |
|
X-Axis Guide Rail |
30 mm |
|
Z-Axis Guide Rail |
35 mm |
|
X-Axis Ball Screw |
Φ32 × 12 mm |
|
Z-Axis Ball Screw |
Φ40 × 12 mm |
|
Positioning Accuracy |
0.005 mm |
|
Repeatability |
0.005 mm |
|
Machining Roundness |
0.003 mm |
|
Machining Cylindricity |
0.006 mm |
|
CNC Control System |
E80 / FANUC Oi-TF |
|
Spindle Motor Power |
15 / 18.5 kW |
|
Maximum Spindle Torque |
71.5 / 95.5 Nm |
|
X-Axis Servo Motor |
1.5 kW |
|
Z-Axis Servo Motor |
3 kW |
|
Voltage |
380V ±10% |
|
Power Requirement |
26 kVA |
|
Power Supply |
3 Phase, 50/60 Hz |
|
Machine Dimensions |
2900 × 1980 × 1800 mm |
|
Machine Weight |
4500 kg |
Typical Applications
The DC600 Horizontal Turning Center is suitable for machining a wide range of medium and large precision components, including:
Automotive Industry
Drive shafts
Gear blanks
Wheel hubs
Transmission housings
Aerospace Industry
Structural components
Engine parts
Precision rotating components
Energy & Industrial Equipment
Valve bodies
Pump components
Bearing housings
Mechanical couplings
General Manufacturing
Flanges
Sleeves
Pipe fittings
Custom-machined metal parts
Quality Assurance
Every machine undergoes strict inspection and performance testing before shipment.
Quality control procedures include:
●Machine geometry inspection
●Spindle accuracy verification
●Ball screw and guideway testing
●CNC system functionality checks
●Trial cutting and performance validation
●Final factory acceptance inspection
Inspection reports can be provided upon request.
Certifications
Our manufacturing and quality management systems comply with internationally recognized standards.
●ISO 9001 Quality Management System
●ISO 14001 Environmental Management System
●ISO 45001 Occupational Health & Safety Management System
Certification documents are available for customer review.
OEM & Distributor Support
We support machine distributors, industrial equipment suppliers, and OEM partners worldwide.
Available services include:
●OEM branding
●Customized machine colors
●Technical documentation support
●Product catalogs and marketing materials
●Spare parts supply
●Remote technical assistance
●Long-term distributor cooperation
Packaging & Global Shipping
To ensure safe transportation during international shipment, each machine is prepared using export-standard packaging procedures.
●Anti-rust surface protection
●Moisture-proof wrapping
●Reinforced wooden export crates
●Secure machine fixation for sea freight transport
Shipping options include EXW, FOB, CIF, CFR, and DDP according to customer requirements.
After-Sales Service
One-Year Warranty
A 12-month warranty is provided covering manufacturing defects and major machine components.
Technical Support
Online technical assistance is available to support installation, operation, and troubleshooting.
Spare Parts Supply
Long-term spare parts availability ensures continuous machine operation and reduced downtime.
Operator Training
Operation manuals, training videos, and remote guidance are provided to help customers quickly start production.
Frequently Asked Questions
Request a Quote
Looking for a reliable CNC turning solution for your manufacturing project or distribution business?
Contact us today to receive factory pricing, technical recommendations, machine specifications, and customized solutions based on your production requirements.
